Temperature Sensor | PT500 | Plastic probe | L 1 m
Product description
FLTSN-P500P100 is a passive sensor for measuring ambient temperature.
The sensor uses a PT500 platinum element with a positive temperature coefficient of resistance and does not require a separate power supply. The cable length is 1 m.
The sensor element is enclosed in a plastic probe which provides an IP65 protection. The sensor is suitable for both indoor and outdoor HVAC applications.
Additional specifications and description
Which parameters are measured and why is it important?
This sensor probe measures ambient temperature. It is a passive sensor, providing accurate measurements for monitoring and control applications.
Temperature plays a crucial role in human comfort and overall well-being. Temperature not only affects how hot or cold a space feels, but also impacts health and productivity. It is important to create an indoor environment that ensures a general sense of comfort for everyone.
What are the configuration and customisation options?
The sensor measures temperature via a PT500 platinum element with an electrical resistance of 500 Ω at 0 °C. It has a positive temperature coefficient of resistance (PTC), which means that the resistance increases when the temperature increases.
Any device with an input for passive temperature sensors can read out the measured temperature.
How is the sensor installed, and what are the power and connectivity requirements?
The plastic sensor probe has a length of 89 mm.
This temperature sensor has an integrated, unshielded 2-wire cable with a length of 1 m. The cable can be extended, if necessary. However, we recommend to keep the cable length limited. The longer the cable length, the higher the influence of the resistance of the cable on the measurement readout. The wires have a cross section of 0,5 mm² and tinned connections, which makes them easy to solder and reduces corrosion. The sensor does not require a separate power supply.
What are the manufacturing quality and protection ratings?
All sensors are designed and manufactured in Europe. Each device is calibrated and tested in our factory. Only high-quality components are used, ensuring long-term stability and accuracy.
The platinum sensor element is enclosed in a black plastic probe made from premium ABS (89 mm x 8 mm), which provides an IP65 protection against ingress of dust and moisture. The simple and practical design makes these probes suitable for a wide range of indoor and outdoor HVAC applications.
