Cable gland M12 - Light grey

Article code W-CG-LG-M12
GTIN 14 5401003900031
Intrastat number 85.47.20.00
Category Enclosure related
Current stock 10 BAG
Factory lead time 5 Day(s)

Product description

CG series are general-purpose cable glands intended as a sealing device for electrical cables passing through an enclosure or panel. The cable gland ensures that the characteristics of the enclosure in which the cable enters can be maintained adequately. CG series can be used to maintain a maximum ingress protection of IP67.
CG-LG-M12 is manufactured in un-reinforced Polyamide 6.0 with light grey colour (RAL7035). For optimal cable sealing, a TPV rubber ring is inserted. It features a thread of M12 x 1,5 and a clamping range of 3 - 6 mm. The cable gland nuts (CN-series) must be ordered separately.

Documents

Additional specifications and description

- Metric connection thread according to EN 50262
- Reducing seal insert to seal cables with smaller outer diameters
- Resistant to common fluids and solvents
- Easy-to-install
- Wide sealing and clamping range
- Anti-vibration protection
