HVAC sensors and trasmitters

Temperature and relative humidity transmitters

The sensors measure temperature and relative humidity and transfer these measured values into an analogue output or a Modbus RTU register. The intelligent sensors feature adjustable ranges of temperature and relative humidity. Their algorithm controls a single analogue / modulating output based on the measured temperature and relative humidity values, which can be used to directly control an EC fan or an actuator powered damper.

	Duct	Room	Outdoor
Article code	DSTHG-2	DSTHF-2	DSTHM-2	RSTHG-2	RSTHF-2	RSTHH-2	RSTHM-2	RWTHM-2	ODTHM
Power supply	18 - 34 VDC / 15-24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM, RJ45 or terminal block	24 VDC PoM
Outputs	2 analogue / modulating outputs ( 0-10 VDC / 0-20 mA / PWM )	Modbus RTU
Temperature range	-30 - 70°C	0 - 50°C	-30 - 70°C
rH range	0 - 100% rH	0 - 95% rH	0 - 100% rH
Modbus RTU
Protection standard	Enclosure: IP54; probe: IP20	IP30	IP65
Extra features	Measure T and rH	Measure T, rH and ambient light

	Flush mounted
Article code	FCTHG	FCTHF	FCTH8
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	85 - 264 VAC / 50 - 60 Hz
Outputs	1 analogue/modulating output ( 0-10 VDC/ 0-20 mA / PWM )
Temperature range	0 - 50°C
rH range	0 - 95% rH
Modbus RTU
Protection standard	IP30
Extra features	Control T and rH; Measure the ambient light; Flush or surface mounting

CO₂ transmitters

The sensors measure temperature, relative humidity and carbon dioxide (CO₂) and transfer these measured values into an analogue / modulating output or a Modbus RTU register. The intelligent sensors feature adjustable temperature, relative humidity and carbon dioxide (CO₂) ranges. Their algorithm controls a single analogue/modulating output based on the measured temperature, relative humidityh and carbon dioxide (CO₂) values, which can be used to directly control an EC fan or an actuator powered damper.

Air quality (TVOC) transmitters

The sensors measure temperature, relative humidity and air quality (TVOC or Total Volatile Organic Compounds) and transfer these measured values into an analogue output or a Modbus RTU register. The intelligent sensors feature adjustable ranges of temperature, relative humidity and air quality (TVOC or Total Volatile Compounds). Their algorithm controls a single analogue / modulating output based on the measured temperature, relative humidity and air quality values, which can be used to directly control an EC fan or an actuator powered damper.

	Duct	Room	Outdoor
Article code	DSMFG-2R	DSMFF-2R	DSMFM-2R	RSMFG-2R	RSMFF-2R	RSMFH-2R	RSMFM-2R	ODMFM-R
Power supply	18 - 34 VDC / 15-24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM
Outputs	3 analogue / modulating outputs ( 0 - 10 VDC / 0 - 20 mA / PWM )	Modbus RTU	3 analogue / modulating outputs ( 0 - 10 VDC / 0 - 20 mA / PWM )	Modbus RTU
Temperature range	-30 - 70°C	0 - 50°C	-30 - 70°C
rH range	0 - 100% rH	0 - 95% rH	0 - 100% rH
CO₂ range	400 – 2.000 ppm
Modbus RTU
Protection standard	Enclosure: IP54; probe: IP20	IP30	Enclosure: IP54; probe: IP20
Extra features	Measure T, rH and CO₂; Replaceable CO₂ sensor element	Measure T, rH, CO₂ and ambient light; Replaceable CO₂ sensor element	Measure T, rH and CO₂; Replaceable CO₂ sensor element

	Duct	Outdoor
Article code	DSMHG-2R	DSMHF-2R	DSMHM-2R	ODMHM-R
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM
Outputs	3 analogue / modulating outputs ( 0 - 10 VDC / 0 - 20 mA / PWM )	Modbus RTU
Temperature range	-30 - 70°C
rH range	0 - 100% rH
CO₂ range	400 – 10.000 ppm
Modbus RTU
Protection standard	Enclosure: IP54; probe: IP20
Extra features	Measure T, rH and CO₂; Special anticorrosion and ammonia coating; Replaceable CO₂ sensor element	Measure T, rH, CO₂ and ambient light; Special anticorrosion and ammonia coating ;Replaceable CO₂ sensor element

	Duct	Room	Flush mounted	Outdoor
Article code	DCMFG-2R	DCMFF-2R	DCMFM-2R	RCMFG-2R	RCMFF-2R	RCMFH-2R	RCMFM-2R	FCMFG-R	FCMFF-R	FCMF8-R	OCMFM-2R
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	85 - 264 VAC / 50 - 60 Hz	24 VDC PoM
Outputs	3 analogue / modulating outputs ( 0 - 10 VDC / 0 - 20 mA / PWM )	Modbus RTU	3 analogue / modulating outputs ( 0 - 10 VDC / 0 - 20 mA / PWM )	Modbus RTU	1 analogue / modulating output ( 0 - 10 VDC / 0 - 20 mA / PWM )	Modbus RTU
Temperature range	-30 - 70°C	0 - 50°C	-30 - 70°C
rH range	0 - 100% rH	0 - 95% rH	0 - 100% rH
CO₂ range	400 – 2.000 ppm	400 – 2.000 ppm
Modbus RTU
Protection standard	Enclosure: IP54; probe: IP20	IP30	Enclosure: IP54; probe: IP20
Extra features	Controls T, rH and CO₂; Replaceable CO₂ sensor element	Controls T, rH and CO₂; Measure the ambient light; Replaceable CO₂ sensor element	Controls T, rH and CO₂; Measure the ambient light; Flush or surface mounting; Replaceable CO₂ sensor element	Control T, rH and CO₂; Measure the ambient light; Replaceable CO₂ sensor element

	Duct	Room	Outdoor
Article code	DSVCG-R	DSVCF-R	DSVCM-R	RSVCG-R	RSVCF-R	RSVCH-R	RSVCM-R	ODVCM-R
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC	24 VDC PoM
Outputs	3 analogue / modulating outputs ( 0-10 VDC / 0-20 mA / PWM )	Modbus RTU	3 analogue / modulating outputs ( 0-10 VDC / 0-20 mA / PWM )	Modbus RTU
Temperature range	-30 - 70°C	0 - 50°C	-30 - 70°C
rH range	0 - 100% rH
TVOC range	1 - 60.000 ppb
CO₂eq range	0 - 60.000 ppm
Modbus RTU
Protection standard	Enclosure: IP54; probe: IP20	IP30	IP65
Extra features	Measure T, rH and TVOC/CO₂eq	Measure T, rH, TVOC/CO₂eq and ambient light

	Flush mounted
Article code	FCVCG-R	FCVCF-R	FCVC8-R
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	85 - 264 VAC / 50 - 60 Hz
Outputs	1 analogue/modulating output ( 0-10 VDC/ 0-20 mA / PWM )
Temperature range	0 - 50°C
rH range	0 - 95% rH
TVOC range	1 - 60.000 ppb
CO₂eq range	0 - 60.000 ppm
Modbus RTU
Protection standard	IP30
Extra features	Controls T, rH, TVOC / CO₂eq; ambient light measurement; CO₂eq cannot control the output

CO and NO₂ transmitters

The sensors measure temperature, relative humidity and carbon monoxide (CO) or nitrogen dioxide (NO₂) and transfer these measured values into an analogue output or a Modbus RTU register. The intelligent sensors feature adjustable ranges of temperature, relative humidity and CO/NO₂. Their algorithm controls a single analogue / modulating output based on the measured temperature, relative humidity and CO values, which can be used to directly control an EC fan or an actuator powered damper.

	Duct	Room	Outdoor
Article code	DSCOG-R	DSCOF-R	DSCOM-R	RSCOG-R	RSCOF-R	RSCOH-R	RSCOM-R	ODCOM-R
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM
Outputs	3 analogue / modulating outputs ( 0-10 VDC / 0-20 mA / PWM )	Modbus RTU
Temperature range	-30 - 70°C	0 - 50°C	-30 - 70°C
rH range	0 - 100% rH	0 - 95% rH	0 - 100% rH
CO range	0 - 1.000 ppm
NO₂ range	0 - 10 ppm
Modbus RTU
Protection standard	Enclosure: IP54; probe: IP20	IP30	IP65
Extra features	Measure T, rH, CO/NO₂	Measure T, rH, CO/NO₂ and ambient light

	Flush mounted
Article code	FCCOG-R	FCCOF-R	FCCO8-R
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	85 - 264 VAC / 50 - 60 Hz
Outputs	1 analogue/modulating output ( 0-10 VDC/ 0-20 mA / PWM )
Temperature range	0 - 50°C
rH range	0 - 95% rH
CO range	0 - 1.000 ppm
NO₂ range	0 - 10 ppm
Modbus RTU
Protection standard	IP30
Extra features	Control T, rH and CO/NO₂; Measure the ambient light; Flush or surface mounting

Differential pressure sensors

Differential pressure transmitters are designed to measure differential pressure, airflow volume or airflow velocity. The measured value is transferred into an analogue output or Modbus RTU register.

HPS series

Differential pressure transmitter to measure differential pressure (Pa), volume flow (m³/hr) or air velocity (m/s).

	HPS series					HPS series					HPS series
Article code	HPS-G--LP	HPS-F--LP	HPS-M--LP	HPS-G-1K0 -2	HPS-F-1K0 -2	HPS-M-1K0 -2	HPS-G-2K0 -2	HPS-F-2K0 -2	HPS-M-2K0 -2	HPS-G-4K0 -2	HPS-F-4K0 -2	HPS-M-4K0 -2	HPS-G-10K0 -2	HPS-F-10K0 -2	HPS-M-10K0 -2
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM
Outputs	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )		Modbus RTU	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )		Modbus RTU	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )		Modbus RTU	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )		Modbus RTU	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )		Modbus RTU
Operating range	-125 – 125 Pa			0 - 1.000 Pa			0 - 2.000 Pa			0 - 4.000 Pa			0 - 10.000 Pa
Selectable response time	0.1 – 10 s					0.1 – 10 s					0.1 – 10 s
Modbus RTU
Protection standard	IP65					IP65					IP65
Extra features	Air velocity detection (by using an external PSET-PTX-200 Pitot tube connection set); Implemented K-factor							Air velocity detection (by using an external PSET-PTX-200 Pitot tube connection set); Implemented K-factor

DPS series

With display - measure differential pressure (Pa), airflow volume (m³/hr) or airflow velocity (m/s).

	DPS series					DPS series					DPS series
Article code	DPS-G--LP	DPS-F--LP	DPS-M--LP	DPS-G-1K0 -2	DPS-F-1K0 -2	DPS-M-1K0 -2	DPS-G-2K0-2	DPS-F-2K0 -2	DPS-M-2K0 -2	DPS-G-4K0-2	DPS-F-4K0 -2	DPS-M-4K0 -2	DPS-G-10K0-2	DPS-F-10K0 -2	DPS-M-10K0 -2
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM
Outputs	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )		Modbus RTU	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )		Modbus RTU	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )		Modbus RTU	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )		Modbus RTU	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )		Modbus RTU
Operating range	-125 – 125 Pa			0 - 1.000 Pa			0 - 2.000 Pa			0 - 4.000 Pa			0 - 10.000 Pa
Selectable response time	0.1 – 10 s					0.1 – 10 s					0.1 – 10 s
Modbus RTU
Protection standard	IP65					IP65					IP65
Extra features	LED display; Air velocity detection (by using an external PSET-PTX-200 Pitot tube connection set); Implemented K-factor							LED display; Air velocity detection (by using an external PSET-PTX-200 Pitot tube connection set); Implemented K-factor

HPD series

Featuring two separate analogue outputs.

	HPD series
Article code	HPD-G-1K0	HPD-F-1K0	HPD-G-2K0	HPD-F-2K0	HPD-G-4K0	HPD-F-4K0	HPD-G-10K0	HPD-F-10K0
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC
Outputs	2 analogue / modulating outputs ( 0-10 VDC / 0-20 mA / PWM )
Operating range	0 - 1.000 Pa		0 - 2.000 Pa		0 - 4.000 Pa		0 - 10.000 Pa
Selectable response time	0.1 – 10 s
Modbus RTU
Protection standard	IP65
Extra features	Implemented K-factor; Independent calibration of the sensors; Independent response time selection for each sensor

DPD series

With display - featuring two separate analogue outputs.

	DPD series
Article code	DPD-G-1K0	DPD-F-1K0	DPD-G-2K0	DPD-F-2K0	DPD-G-4K0	DPD-F-4K0	DPD-G-10K0	DPD-F-10K0
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC
Outputs	2 analogue / modulating outputs ( 0-10 VDC / 0-20 mA / PWM )
Operating range	0 - 1.000 Pa		0 - 2.000 Pa		0 - 4.000 Pa		0 - 10.000 Pa
Selectable response time	0.1 – 10 s
Modbus RTU
Protection standard	IP65
Extra features	LED display; Implemented K-factor; Independent calibration of the sensors; Independent response time selection for each sensor

Differential pressure controllers

These differential pressure controllers generate a control signal to maintain the differential pressure, airflow volume or airflow velocity at the requested value. Via Modbus RTU, it is possible to define one or more set points.

HPSP series

Designed to control fans and guarantee a constant supply of fresh air.

	HPSP series					HPSP series
Article code	HPSPG-LP	HPSPF-LP	HPSPM-LP	HPSPG-1K0 -2	HPSPF-1K0 -2	HPSPG-2K0 -2	HPSPF-2K0 -2	HPSPG-4K0 -2	HPSPF-4K0 -2	HPSPG-10K0 -2	HPSPF-10K0 -2
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC
Outputs	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )		Modbus RTU	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )
Operating range	-125 – 125 Pa			0 - 1.000 Pa		0 - 2.000 Pa		0 - 4.000 Pa		0 - 10.000 Pa
Selectable response time	0.1 – 10 s					0.1 – 10 s
Modbus RTU
Protection standard	IP65					IP65
Extra features	Air velocity control (by using an external PSET-PTX-200 Pitot tube connection set); Implemented K-factor

DPSP series

With display - designed to control fans and guarantee a constant supply of fresh air.

	DPSP series					DPSP series
Article code	DPSPG-LP	DPSPF-LP	DPSPM-LP	DPSPG-1K0 -2	DPSPF-1K0 -2	DPSPG-2K0 -2	DPSPF-2K0 -2	DPSPG-4K0 -2	DPSPF-4K0 -2	DPSPG-10K0 -2	DPSPF-10K0 -2
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	24 VDC PoM	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC
Outputs	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )		Modbus RTU	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )
Operating range	-125 – 125 Pa			0 - 1.000 Pa		0 - 2.000 Pa		0 - 4.000 Pa		0 - 10.000 Pa
Selectable response time	0.1 – 10 s					0.1 – 10 s
Modbus RTU
Protection standard	IP65					IP65
Extra features	LED display; Air flow velocity control (by using an external PSET-PTX-200 Pitot tube connection set); Implemented K-factor

SPS2 series

Features two differential pressure setpoints (high/low or day/night mode).

	SPS2 series
Article code	SPS2G-2K0	SPS2F-2K0	SPS2G-6K0	SPS2F-6K0
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC	18 - 34 VDC / 15 - 24 VAC ± 10%	18 - 34 VDC
Outputs	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )
Operating range	0 - 2.000 Pa		0 - 6.000 Pa
Modbus RTU
Protection standard	IP65
Extra features	Integrated PI control; K-factor and setpoint setting; Two switchable setpoints

HPSA series

Designed to control actuator powered dampers.

	HPSA series
Article code	HPSAG-1K0 -2	HPSAG-2K0 -2	HPSAF-1K0 -2	HPSAF-2K0 -2
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%		18 - 34 VDC
Outputs	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )
Operating range	0 - 1.000 Pa	0 - 2.000 Pa	0 - 1.000 Pa	0 - 2.000 Pa
Modbus RTU
Protection standard	IP65
Extra features	Integrated PI control and setpoint setting; Automatic range selection according to the selected setpoint

DPSA series

Designed to control actuator powered dampers.

	DPSA series
Article code	DPSAG-1K0 -2	DPSAG-2K0 -2	DPSAF-1K0 -2	DPSAF-2K0 -2
Power supply	18 - 34 VDC / 15 - 24 VAC ± 10%		18 - 34 VDC
Outputs	1 analogue / modulating output ( 0-10 VDC / 0-20 mA / PWM )
Operating range	0 - 1.000 Pa	0 - 2.000 Pa	0 - 1.000 Pa	0 - 2.000 Pa
Modbus RTU
Protection standard	IP65
Extra features	Integrated PI control and setpoint setting; Automatic range selection according to the selected setpoint

Differential pressure switches

Differential pressure relays or switches can be used to detect differential pressure levels. The activation point can be adjusted via a trimmer on the pressure switch.

PSW series

Used to detect differential pressure levels.

	PSW series
Article code	PSW--200	PSW--500	PSW--200-PVC	PSW--500-PVC
Max operating pressure	2.500 Pa
Pa range	20 - 200	50 - 500	20 - 200	50 - 500
mBar range	0.2 - 2	0.5 - 5	0.2 - 2	0.5 - 5
ΔP, Pa (mBar)	10 (0.1)	20 (0.2)	10 (0.1)	20 (0.2)
Operating range	0 - 2.000 Pa
Protection standard	IP54
Extra features	Adjustable switching point		Adjustable switching point; Delivered with a set of flexible transparent PVC tubes (L 2 m)

Temperature

Measure temperature and transfer the measured value into an analogue output or a Modbus RTU register. Also passive temperature sensors are available. Next to ambient temperature measurement, we also have solutions to measure wall temperature or water temperature (external temperature measurement of hot water pipes).

	Room sensor			Thermostat
Article code	ROTSN-P100	ROTSN-P500	ROTSN-P1K0	IMRT-0-40
Type	Passive room temperature sensor			Mechanical thermostat
Temperature range				0 - 40°C
Modbus RTU
Protection standard	IP30			IP54

	FLTSN								TUTSN
Article code	FLTSN-P100-010	FLTSN-P500-010	FLTSN-P500-040	FLTSN-P1K0-010	FLTSN-P1K0-040	FLTSN-N-3K3A1-010	FLTSN-N-1K4A1-010	FSTSN-P500-010	TUTSN-P500-150	TUTSN-P500-250	TUTSN-P1K0-150	TUTSN-P1K0-250
Type	Flying lead temperature probe							Shielded flying lead temperature probe	Passive tube temperature probe
Flying leads length	1 m, can be extended		4 m, can be extended	1 m, can be extended	4 m, can be extended	1 m, can be extended		900 mm	1 m
Flying leads cross section	0,5 mm²						0,5 mm²
Modbus RTU
Protection standard	IP65								IP30
Extra features	Positive temperature coefficient					Negative temperature coefficient		Positive temperature coefficient	Easy installation; Wide measurement range


Article code	PSET-PVC-200	PSET-QF-200	PSET-PTS-200	PSET-PTL-200
Nozzles material	Plastic (ABS)	Aluminum
Pitot tube			POLYFLAM® RABS 90000 UV5, grey
Tube material	PVC, transparent
Tube length	200 cm
Working pressure	Max. 600.000 Pa		Max. 10.000 Pa
Operating temperature	Max. 60 °C		Max. 96 °C
Measures	Differential pressure [Pa]; Volume flow [m³/h]		Air velocity [m/s]; Volume flow [m³/h]


Article code	TUBE-PVC-0705
Tube material	PVC, transparent
Tube length	100 m
Inner diameter	5 mm
Outer diameter	7 mm
Working pressure	Max. 10.000 Pa
Operating temperature	Max. 60 °C

Discover more

Room sensors:

Flush mounted sensors:

Duct sensors:

Outdoor sensors:

Temperature and relative humidity transmitters

Standard

Intelligent

CO₂ transmitters

Standard

Extra corrosion protection

Intelligent

Air quality (TVOC) transmitters

Standard

Intelligent

CO and NO₂ transmitters

Standard

Intelligent
