Room sensors

Room sensors:

HVAC sensors in a smooth, contemporary design that will fit seamlessly with most interiors. Suited for indoor mounting. As standard, they measure temperature, relative humidity and ambient light.

Flush mounted sensors

Flush mounted sensors:

HVAC sensors suited for flush mounting. As standard, they measure temperature, relative humidity and ambient light. Their algorithm controls a single analogue / modulating output based on the measured temperature and relative humidity values, which can be used to directly control an EC fan or an actuator powered damper.

Duct sensors

Duct sensors:

HVAC sensors in duct enclosure for measurements in air ducts. As standard, they measure temperature and relative humidity.

Outdoor sensors

Outdoor sensors:

HVAC sensors in IP65 enclosure, suited for outdoor applications or applications in harsh environments. As standard, they measure temperature, relative humidity and ambient light and feature 'Power over Modbus' or PoM connection. This means that Modbus RTU communication and 24 VDC power supply can be connected via one RJ45 connector.

Temperature and relative humidity

The sensors measure temperature and relative humidity and transfer these measured values into an analogue output or a Modbus RTU register. The intelligent sensors feature adjustable ranges of temperature and relative humidity. Their algorithm controls a single analogue / modulating output based on the measured temperature and relative humidity values, which can be used to directly control an EC fan or an actuator powered damper.

Standard - duct, room, outdoor

Standard

Duct, Room, Outdoor

Intelligent - Flush mounted

Intelligent

Flush mounted

Temperature, relative humidity and CO2

The sensors measure temperature, relative humidity and carbon dioxide (CO2) and transfer these measured values into an analogue / modulating output or a Modbus RTU register. The intelligent sensors feature adjustable temperature, relative humidity and carbon dioxide (CO2) ranges. Their algorithm controls a single analogue/modulating output based on the measured temperature, relative humidityh and carbon dioxide (CO2) values, which can be used to directly control an EC fan or an actuator powered damper.

Standard - duct, room, outdoor

Standard

Duct, Room, Outdoor

Extra corrosion protection - duct, outdoor

Extra corrosion protection

Duct, Outdoor

Intelligent - duct, room, flush mounted, outdoor

Intelligent

Duct, Room, Flush mounted, Outdoor

Temperature, relative humidity and TVOC/CO2eq

The sensors measure temperature, relative humidity and air quality (TVOC or Total Volatile Organic Compounds) and transfer these measured values into an analogue output or a Modbus RTU register. The intelligent sensors feature adjustable ranges of temperature, relative humidity and air quality (TVOC or Total Volatile Compounds). Their algorithm controls a single analogue / modulating output based on the measured temperature, relative humidity and air quality values, which can be used to directly control an EC fan or an actuator powered damper.

Standard - duct, room, outdoor

Standard

Duct, Room, Outdoor

Intelligent - Flush mounted

Intelligent

Flush mounted

Temperature, relative humidity and CO/NO2

The sensors measure temperature, relative humidity and carbon monoxide (CO) or nitrogen dioxide (NO2) and transfer these measured values into an analogue output or a Modbus RTU register. The intelligent sensors feature adjustable ranges of temperature, relative humidity and CO/NO2. Their algorithm controls a single analogue / modulating output based on the measured temperature, relative humidity and CO values, which can be used to directly control an EC fan or an actuator powered damper.

Standard - duct, room, outdoor

Standard

Duct, Room, Outdoor

Intelligent - Flush mounted

Intelligent

Room - flush mounted

Differential pressure sensors

Differential pressure transmitters are designed to measure differential pressure, airflow volume or airflow velocity. The measured value is transferred into an analogue output or Modbus RTU register.

HPS series

HPS series

Differential pressure transmitter to measure differential pressure (Pa), volume flow (m³/hr) or air velocity (m/s).

DPS series

DPS series

With display - measure differential pressure (Pa), airflow volume (m³/hr) or airflow velocity (m/s).

HPD series

HPD series

Featuring two separate analogue outputs.

DPD series

DPD series

With display - featuring two separate analogue outputs.

Differential pressure controllers

These differential pressure controllers generate a control signal to maintain the differential pressure, airflow volume or airflow velocity at the requested value. Via Modbus RTU, it is possible to define one or more set points.

HPSP series

HPSP series

Designed to control fans and guarantee a constant supply of fresh air.

DPSP series

DPSP series

With display - designed to control fans and guarantee a constant supply of fresh air.

SPS2 series

SPS2 series

Features two differential pressure setpoints (high/low or day/night mode).

SPSA series

SPSA series

Designed to control actuator powered dampers.

Differential pressure switches

Differential pressure relays or switches can be used to detect differential pressure levels. The activation point can be adjusted via a trimmer on the pressure switch.

PSW series

PSW series

Used to detect differential pressure levels.

Temperature

Measure temperature and transfer the measured value into an analogue output or a Modbus RTU register. Also passive temperature sensors are available. Next to ambient temperature measurement, we also have solutions to measure wall temperature or water temperature (external temperature measurement of hot water pipes).

Room sensor

Room

HVAC sensors in a smooth, contemporary design that will fit seamlessly with most interiors.

Duct

Duct

HVAC sensors in duct enclosure for measurements in air ducts.

Duct

Outdoor

HVAC sensors in IP65 enclosure, suited for outdoor applications or applications in harsh environments.

Probes

Probes

Passive temperature sensors

Probes

Fluid pipes

DTP series designed for external temperature measurements of hot water pipes.

Accessories

Accessories for professional installation of differential pressure transmitters and controllers: transparent PVC tubes, differential pressure connection sets and Pitot tubes for airflow velocity measurement.

PSET

PSET

TUBE

TUBE
